Advanced Usage
This guide covers some of the more advanced features, patterns and configuration options of AltTester® Unity SDK.
AltTester® input
AltTester® Unity SDK has an Input
class which overrides the Input class implemented by Unity. This war® intercepts the input actions to be performed in the instrumented app and simulates them through this class.
In case you are using assembly definitions inside your project, you will have to reference the AltTesterUnitySDK.asmdef
in all your .asmdef files which use input actions.
AltTester® input vs. regular input
AltTester®’s custom input is active, by default, in any instrumented build. This means that certain input related actions (the ones that are part of Unity’s Input
class) will be inactive for regular input (the device’s input). Because of this, pressing a key from the keyboard for example will not have any effect on the app. However, the simulated input from the tests, like the PressKey
command, will be able to manipulate the object within the scene. While the AltTester® input is active, the icon from the right bottom corner is green. You can change this behaviour by clicking on the AltTester®’s icon and unchecking the box with the AltTester® Input
message. Now the icon will turn darker, signaling that the regular input is active. In this state, you can interfere with the object from the app using the keyboard or other input. Keep in mind that, input actions from the AltTester® Desktop won’t have any effect while regular input is active. At the same time, if you want to run some automated tests, the AltTester® input will be activated automatically for you.
Build apps from the command line
To build your Unity application from command line you need a static method in
your project that handles the build logic. To instrument your Unity application
with AltTester® Unity SDK, your build method must define ALTTESTER
scripting
symbol and must insert AltTester® Prefab in the first scene of the app.
Depending on your project’s setup, there are two ways in which apps can be built from the command line:
Note
AltTester® Unity SDK does not work by default in release mode. If you instrument your app in release mode, AltTester® Prefab self removes from the scenes and the socket server does not start. Best case practice is to customize your build script to insert AltTester® Prefab only in Debug mode.
If you do want to use AltTester® Unity SDK in release mode see Using AltTester® Unity SDK in Release mode section.
1. If you already have a custom build method for your app
If you already have a custom build method for your app, you can add the following lines to your build method. Also, the BuildPlayerOptions should check for BuildOptions.Development and BuildOptions.IncludeTestAssemblies.
var buildTargetGroup = BuildTargetGroup.Android;
AltBuilder.AddAltTesterInScriptingDefineSymbolsGroup(buildTargetGroup);
if (buildTargetGroup == UnityEditor.BuildTargetGroup.Standalone) {
AltBuilder.CreateJsonFileForInputMappingOfAxis();
}
var instrumentationSettings = new AltInstrumentationSettings();
AltBuilder.InsertAltInScene(FirstSceneOfTheApp, instrumentationSettings);
Note
Change buildTargetGroup
above to the target group for which you are
building.
2. If you create a new custom build method for your app
The following example script can be used. It sets all the project settings needed and uses the same two important lines from point 1 above.
This example method is configured for the Android platform, so make sure to update it based on your target platform.
static void BuildFromCommandLine () {
try {
BuildPlayerOptions buildPlayerOptions = new BuildPlayerOptions();
buildPlayerOptions.scenes = new string[] {
"Assets/AltTester/Examples/Scenes/Scene 1 AltDriverTestScene.unity",
"Assets/AltTester/Examples/Scenes/Scene 2 Draggable Panel.unity",
"Assets/AltTester/Examples/Scenes/Scene 3 Drag And Drop.unity",
"Assets/AltTester/Examples/Scenes/Scene 4 No Cameras.unity",
"Assets/AltTester/Examples/Scenes/Scene 5 Keyboard Input.unity",
"Assets/AltTester/Examples/Scenes/Scene 7 Drag And Drop NIS.unity",
"Assets/AltTester/Examples/Scenes/Scene 7 New Input System Actions.unity",
"Assets/AltTester/Examples/Scenes/Scene 8 Draggable Panel NIP.unity",
"Assets/AltTester/Examples/Scenes/Scene 9 NIS.unity",
"Assets/AltTester/Examples/Scenes/Scene 10 Sample NIS.unity,
"Assets/AltTester/Examples/Scenes/Scene 11 ScrollView Scene.unity",
"Assets/AltTester/Examples/Scenes/Scene6.unity"
};
buildPlayerOptions.locationPathName = "sampleGame.apk";
buildPlayerOptions.target = BuildTarget.Android;
buildPlayerOptions.options = BuildOptions.Development | BuildOptions.IncludeTestAssemblies | BuildOptions.AutoRunPlayer;
// Setup for AltTester
var buildTargetGroup = BuildTargetGroup.Android;
AltBuilder.AddAltTesterInScriptingDefineSymbolsGroup (buildTargetGroup);
if (buildTargetGroup == UnityEditor.BuildTargetGroup.Standalone)
AltBuilder.CreateJsonFileForInputMappingOfAxis();
var instrumentationSettings = new AltInstrumentationSettings();
AltBuilder.InsertAltInScene (buildPlayerOptions.scenes[0], instrumentationSettings);
var results = BuildPipeline.BuildPlayer (buildPlayerOptions);
AltBuilder.RemoveAltTesterFromScriptingDefineSymbols (BuildTargetGroup.Android);
} catch (Exception exception) {
Debug.LogException (exception);
}
}
The following command is used to call the build method:
<UnityPath>/Unity -projectPath $CI_PROJECT_DIR -executeMethod BuilderClass.BuildFromCommandLine -logFile logFile.log -quit
You can find more information about the build command and arguments here.
Note
After building from the command line you can run the tests by using the commands from the next section.
How to make a production build
There is no need to remove the AltTester® package entirely from the project, only the ALTTESTER
Scripting Define Symbol should be deleted from the Player Settings. Also, make sure that the Keep ALTTESTER symbol defined
checkbox is unchecked. After that, you can build your app normally as you would do in Unity.
Run tests from the command line
In order to run tests from the command line you can use the following example commands:
Available AltTester® SDK command line arguments:
-testsClass
- runs tests from given class/classes
Example command running tests from a single test class:
<UnityPath>/Unity -projectPath $PROJECT_DIR -executeMethod AltTester.AltTesterUnitySDK.Editor.AltTestRunner.RunTestFromCommandLine -testsClass MyTestClass -logFile logFile.log -batchmode -quit
Example command running tests from two test classes:
<UnityPath>/Unity -projectPath $PROJECT_DIR -executeMethod AltTester.AltTesterUnitySDK.Editor.AltTestRunner.RunTestFromCommandLine -testsClass MyTestClass1 MyTestClass2 -logFile logFile.log -batchmode -quit
-tests
- runs given test/tests
Example command running a single test:
<UnityPath>/Unity -projectPath $PROJECT_DIR -executeMethod AltTester.AltTesterUnitySDK.Editor.AltTestRunner.RunTestFromCommandLine -tests MyTestClass.MyTestName -logFile logFile.log -batchmode -quit
Example command running two tests:
<UnityPath>/Unity -projectPath $PROJECT_DIR -executeMethod AltTester.AltTesterUnitySDK.Editor.AltTestRunner.RunTestFromCommandLine -tests MyTestClass1.MyTestName1 MyTestClass2.MyTestName2 -logFile logFile.log -batchmode -quit
-testsAssembly
- runs tests from given assembly/assemblies
Example command running all tests from given assembly:
<UnityPath>/Unity -projectPath $PROJECT_DIR -executeMethod AltTester.AltTesterUnitySDK.Editor.AltTestRunner.RunTestFromCommandLine -testsAssembly MyAssembly -logFile logFile.log -batchmode -quit
Example command running tests from two assemblies:
<UnityPath>/Unity -projectPath $PROJECT_DIR -executeMethod AltTester.AltTesterUnitySDK.Editor.AltTestRunner.RunTestFromCommandLine -testsAssembly MyAssembly1 MyAssembly2 -logFile logFile.log -batchmode -quit
-reportPath
- the xml test report will be generated here
<UnityPath>/Unity -projectPath $PROJECT_DIR -executeMethod AltTester.AltTesterUnitySDK.Editor.AltTestRunner.RunTestFromCommandLine -tests MyFirstTest.TestStartGame -reportPath $PROJECT_DIR/testReport.xml -logFile logFile.log -batchmode -quit
mvn test
Using the unittest
module:
python -m unittest <name_of_your_test_file.py>
Using the pytest
package:
pytest <name_of_your_test_file.py>
robot <name_of_your_test_file.robot>
Run tests on a Continuous Integration Server
Instrument your app build with AltTester® Unity SDK from Unity or by building from the command line.
Start the app build on a device.
Run your tests - see commands in the “Run tests from the command line” section.
An example CI configuration file can be viewed in the GitLab repository.
What is reverse port forwarding and when to use it
Reverse port forwarding, is the behind-the-scenes process of intercepting data traffic and redirecting it from a device’s IP and/or port to the computer’s IP and/or port.
When you run your app instrumented with AltTester® Unity SDK on a device, you need to tell your build how to connect to the AltTester® Server.
Reverse port forwarding can be set up either through the command line or in the test code by using the methods available in the AltTester® SDK classes.
The following are some cases when reverse port forwarded is needed:
How to setup reverse port forwarding
In case of Android
Reverse port forwarding can be set up in two ways:
through the command line using ADB
in the test code by using the methods available in the AltTester® SDK classes
All methods listed above require that you have ADB installed.
For further information including how to install ADB, check this article.
In case of iOS
Unfortunately, IProxy does not have a way of setting up reverse port forwarding. As a workaround, to connect the device via USB you should follow the steps below:
set the iOS device as a Personal Hotspot
enable Hotspot via USB on the machine running the AltTester® Server
for this to work, you need to make sure that you have the
Disable unless needed
toggle disabled in the Network settings for the USB connection
the hotspot network and the first device to connect to it are most of the time on
172.20.10.2
so you could set this IP for builds for iOS
add the IP of the machine running the AltTester® Server to the first input field in the green popup from the instrumented app/game
In the routing table, the personal hotspot network would be secondary, therefore the traffic shouldn’t be redirected through the hotspot:
Reverse port forwarding using the following command:
adb [-s UDID] reverse tcp:device_port tcp:local_port.
Not available. A workaround is described above.
Use the following static methods from the AltReversePortForwarding class in your test file:
ReversePortForwardingAndroid
ReversePortForwardingAndroid(int remotePort = 13000, int localPort = 13000, string deviceId = "", string adbPath = "")RemoveReversePortForwardingAndroid
RemoveReversePortForwardingAndroid(int remotePort = 13000, string deviceId = "", string adbPath = "")
Example test file:
using AltTester.AltTesterUnitySDK.Driver; using AltTester.AltTesterUnitySDK.Driver.AltReversePortForwarding; using NUnit.Framework; public class MyFirstTest { private AltDriver altDriver; [OneTimeSetUp] public void SetUp() { AltReversePortForwarding.ReversePortForwardingAndroid(); altDriver = new AltDriver(); } [OneTimeTearDown] public void TearDown() { altDriver.Stop(); AltReversePortForwarding.RemoveReversePortForwardingAndroid(); } [Test] public void TestStartGame() { altDriver.LoadScene("Scene 2 Draggable Panel"); altDriver.FindObject(By.NAME, "Close Button").Tap(); altDriver.FindObject(By.NAME, "Button").Tap(); var panelElement = altDriver.WaitForObject(By.NAME, "Panel"); Assert.IsTrue(panelElement.enabled); } }
Not available. A workaround is described above.
Use the following static methods from the AltReversePortForwarding class in your test file:
reversePortForwardingAndroid
reversePortForwardingAndroid(int remotePort = 13000, int localPort = 13000, string deviceId = "", string adbPath = "")removeReverseForwardingAndroid
removeReverseForwardingAndroid(int remotePort = 13000, string deviceId = "", string adbPath = "")
Example test file:
import org.junit.AfterClass; import org.junit.Assert; import org.junit.BeforeClass; import org.junit.Test; import com.alttester.AltReversePortForwarding; import com.alttester.AltDriver; import com.alttester.AltObject; import com.alttester.Commands.FindObject.AltFindObjectsParameters; import com.alttester.Commands.FindObject.AltWaitForObjectsParameters; import java.io.IOException; public class MyFirstTest { private static AltDriver altDriver; @BeforeAll public static void setUp() throws IOException { AltReversePortForwarding.reversePortForwardingAndroid(); altDriver = new AltDriver(); } @AfterAll public static void tearDown() throws Exception { altDriver.stop(); AltReversePortForwarding.removeReversePortForwardingAndroid(); } @Test public void openClosePanelTest() { altDriver.loadScene(new AltLoadSceneParams.Builder("Scene 2 Draggable Panel").build()); AltFindObjectsParams altFindObjectsParametersCamera = new AltFindObjectsParams.Builder( AltDriver.By.PATH, "//Main Camera") .build(); AltObject camera = altDriver.findObject(altFindObjectsParametersCamera); AltFindObjectsParams closeButtonObjectsParameters = new AltFindObjectsParams.Builder( AltDriver.By.NAME, "Close Button") .withCamera(AltDriver.By.ID, String.valueOf(camera.id)) .build(); altDriver.findObject(closeButtonObjectsParameters).tap(); AltFindObjectsParams buttonObjectsParameters = new AltFindObjectsParams.Builder( AltDriver.By.NAME, "Button") .withCamera(AltDriver.By.ID, String.valueOf(camera.id)) .build(); altDriver.findObject(buttonObjectsParameters).tap(); AltFindObjectsParams panelObjectsParameters = new AltFindObjectsParams.Builder( AltDriver.By.NAME, "Panel") .withCamera(AltDriver.By.ID, String.valueOf(camera.id)) .build(); AltWaitForObjectsParams panelWaitForObjectsParameters = new AltWaitForObjectsParams.Builder( panelObjectsParameters).build(); AltObject panelElement = altDriver.waitForObject(panelWaitForObjectsParameters); Assertions.assertTrue(panelElement.isEnabled()); } }
Not available. A workaround is described above.
Use the following static methods from the AltReversePortForwarding class in your test file:
reverse_port_forwarding_android
reverse_port_forwarding_android(device_port = 13000, local_port = 13000, device_id = "")remove_reverse_port_forwarding_android
remove_reverse_port_forwarding_android(device_port = 13000, device_id = "")
Example test file:
import unittest from alttester import * class MyFirstTest(unittest.TestCase): alt_driver = None @classmethod def setUpClass(cls): AltReversePortForwarding.reverse_port_forwarding_android() cls.alt_driver = AltDriver() @classmethod def tearDownClass(cls): cls.alt_driver.stop() AltReversePortForwarding.remove_reverse_port_forwarding_android() def test_open_close_panel(self): self.alt_driver.load_scene("Scene 2 Draggable Panel") self.alt_driver.find_object(By.NAME, "Close Button").tap() self.alt_driver.find_object(By.NAME, "Button").tap() panel_element = self.alt_driver.wait_for_object(By.NAME, "Panel") self.assertTrue(panel_element.enabled)
Not available. A workaround is described above.
Use the following static methods from the AltReversePortForwarding class in your test file:
- Reverse Port Forwarding Android
Reverse Port Forwarding Android device_port=13000 local_port=13000 device_id=your_device_id
- Remove Reverse Port Forwarding Android
Remove Reverse Port Forwarding Android device_port=13000
Example test file:
*** Settings*** Library AltTesterLibrary Suite Setup SetUp Tests Suite Teardown Teardown Tests *** Test Cases *** Test Resize Panel Load Scene Scene 2 Draggable Panel ${alt_object}= Find Object NAME Resize Zone ${alt_object_x}= Get Object X ${alt_object} ${alt_object_y}= Get Object Y ${alt_object} ${position_init}= Create List ${alt_object_x} ${alt_object_y} ${screen_position}= Get Screen Position ${alt_object} ${new_x}= Evaluate ${alt_object_x}-200 ${new_y}= Evaluate ${alt_object_y}-200 ${new_screen_position}= Create List ${new_x} ${new_y} Swipe ${screen_position} ${new_screen_position} duration=2 ${alt_object}= Find Object NAME Resize Zone ${alt_object_x}= Get Object X ${alt_object} ${alt_object_y}= Get Object Y ${alt_object} ${position_final}= Create List ${alt_object_x} ${alt_object_y} Should Not Be Equal ${position_init} ${position_final} *** Keywords *** SetUp Tests Reverse Port Forwarding Android Initialize Altdriver Teardown Tests Stop Altdriver Remove Reverse Port Forwarding Android
Not available. A workaround is described above.
Note
The default port on which the AltTester® Unity SDK is running is 13000. The port can be changed from the green popup. Make sure to press Restart after modifying its value.
Connect AltTester® Unity SDK running inside the app to AltTester® Server
There are multiple scenarios:
Establish connection when the instrumented app and the test code are running on the same machine
Establish connection when the app is running on a device connected via USB
Establish connection via IP when the app is running on a device
Establish connection when different instances of the same app are running on multiple devices
Establish connection when multiple instances of the same application are running on the same device
Establish connection when the instrumented app and the test code are running on the same machine
Start AltTester® Server on your machine by opening AltTester® Desktop. The server will be listening on port 13000 by default.
Open your instrumented app on the same machine. It will automatically connect to AltTester® Server. The server identifies the app using the appName.
Connect your tests to the server using the line below in your OneTimeSetup(). Start your tests on the machine used before. Make sure that AltTester® Server, the instrumented app and your tests are using the same port. Data transmission happens on localhost.
altDriver = new AltDriver (host: "127.0.0.1", port: 13000, appName: "MyApp");
altDriver = new AltDriver ("127.0.0.1", 13000, "MyApp");
cls.alt_driver = AltDriver(host="127.0.0.1", port=13000, app_name="MyApp")
Initialize Altdriver host=127.0.0.1 port=13000 app_name=MyApp
In this case reverse port forwarding is not needed as both the app and tests are using localhost:13000.
Establish connection when the app is running on a device connected via USB
Start AltTester® Server on your machine by opening AltTester® Desktop. The server will be listening on port 13000 by default.
Open your instrumented app on your device.
Use Reverse Port Forwarding to direct the data traffic from the device’s port to the computer’s port. After this, your app will be connected to AltTester® Server. The server identifies the app using the appName.
Connect your tests to AltTester® Server using the line below in your OneTimeSetup(). Start your tests on the machine used before. Make sure that AltTester® Server, the instrumented app and your tests are using the same port. Data transmission happens on localhost.
altDriver = new AltDriver (host: "127.0.0.1", port: 13000, appName: "MyApp");
altDriver = new AltDriver ("127.0.0.1", 13000, "MyApp");
cls.alt_driver = AltDriver(host="127.0.0.1", port=13000, app_name="MyApp")
Initialize Altdriver host=127.0.0.1 port=13000 app_name=MyApp
Establish connection via IP when the app is running on a device
Start AltTester® Server on your machine by opening AltTester® Desktop. The server will be listening on port 13000 by default.
Open your instrumented app on your device.
Change the host from the green popup in your instrumented build to the machine’s IP AltTester® Server is running on. The server identifies the app using the appName.
Connect your tests to AltTester® Server using the line below in your OneTimeSetup(). Start your tests on the machine used before. Make sure that AltTester® Server, the instrumented app and your tests are using the same port. Data transmission between tests and server happens on localhost; transmission between device and server happens on the host’s IP.
altDriver = new AltDriver (host: "127.0.0.1", port: 13000, appName: "MyApp");
altDriver = new AltDriver ("127.0.0.1", 13000, "MyApp");
cls.alt_driver = AltDriver(host="127.0.0.1", port=13000, app_name="MyApp")
Initialize Altdriver host=127.0.0.1 port=13000 app_name=MyApp
In this case Reverse Port Forwarding is not needed. Despite that, it is recommended to use reverse port forwarding since IP addresses could change and would need to be updated more frequently.
Establish connection when different instances of the same app are running on multiple devices
Connection through IP
Start AltTester® Server on your machine by opening AltTester® Desktop. The server will be listening on port 13000 by default.
Open your instrumented app on your devices. Make sure they have different names. In case you want to change the name, you can do that in the green popup. There is no need to make another instrumented build.
Change the hosts from the green popups in your instrumented builds to the machine’s IP AltTester® Server is running on. The server identifies the apps using the appName.
Connect your tests to AltTester® Server using the line below in your OneTimeSetup(). You will need to create 2 AltDrivers as you have 2 devices. AltDriver1 will communicate with device1 and AltDriver2 with device2. Start your tests on the machine used before. Make sure that AltTester® Server, the instrumented app and your tests are using the same port. Data transmission between tests and server happens on localhost; transmission between devices and server happens on the host’s IP.
altDriver1 = new AltDriver (host: "127.0.0.1", port: 13000, appName: "MyApp1");
altDriver2 = new AltDriver (host: "127.0.0.1", port: 13000, appName: "MyApp2");
altDriver1 = new AltDriver ("127.0.0.1", 13000, "MyApp1");
altDriver2 = new AltDriver ("127.0.0.1", 13000, "MyApp2");
cls.alt_driver1 = AltDriver(host="127.0.0.1", port=13000, app_name="MyApp1")
cls.alt_driver2 = AltDriver(host="127.0.0.1", port=13000, app_name="MyApp2")
Initialize Altdriver1 host=127.0.0.1 port=13000 app_name=MyApp1
Initialize Altdriver2 host=127.0.0.1 port=13000 app_name=MyApp2
The same happens with n devices. Repeat the steps n times.
Connection through USB
Use reverse port forwarding for both devices. Data transmission happens exclusively on localhost. Ex. with 2 Android devices:
adb -s deviceId1 reverse tcp:13000 tcp:1300
adb -s deviceId2 reverse tcp:13000 tcp:1300
Establish connection when multiple instances of the same application are running on the same device
Connection through IP
Start AltTester® Server on your machine by opening AltTester® Desktop. The server will be listening on port 13000 by default.
Open your instrumented apps on your device. Make sure they have different names. In case you want to change the name, you can do that in the green popup. There is no need to make another instrumented build.
Change the hosts from the green popups in your instrumented builds to the machine’s IP AltTester® Server is running on. The server identifies the apps using the appName.
Connect your tests to AltTester® Server using the line below in your OneTimeSetup(). You will need to create 2 AltDrivers as you have 2 apps. AltDriver1 will communicate with app1 and AltDriver2 with app2. Start your tests on the machine used before. Make sure that AltTester® Server, the instrumented app and your tests are using the same port. Data transmission between tests and server happens on localhost; transmission between device and server happens on the host’s IP.
altDriver1 = new AltDriver (host: "127.0.0.1", port: 13000, appName: "MyApp1");
altDriver2 = new AltDriver (host: "127.0.0.1", port: 13000, appName: "MyApp2");
altDriver1 = new AltDriver ("127.0.0.1", 13000, "MyApp1");
altDriver2 = new AltDriver ("127.0.0.1", 13000, "MyApp2");
cls.alt_driver1 = AltDriver(host="127.0.0.1", port=13000, app_name="MyApp1")
cls.alt_driver2 = AltDriver(host="127.0.0.1", port=13000, app_name="MyApp2")
Initialize Altdriver1 host=127.0.0.1 port=13000 app_name=MyApp1
Initialize Altdriver2 host=127.0.0.1 port=13000 app_name=MyApp2
Connection through USB
Use Reverse Port Forwarding. Data transmission happens exclusively on localhost.
Important
On mobile devices, AltDriver can interact only with a single app at a time and the app needs to be in focus. In case of 2 drivers and 2 apps, you need to switch (in your test scripts) between the applications. This is due to the fact that on Android/iOS only one application is in focus at a time, even when using split screen mode.
Execute tests concurrently
In the AltDriver
constructor you have the option to specify multiple tags. The available tags are: app name, platform, platform version, device instance id and app id. The app id can be used to uniquely identify an app. In case you specify no tags, the tests will be run on a randomly chosen app.
Keep in mind that, the tags given in the constructor will choose one random free app satisfying the requirements. Only one test can run on one app simultaneously. If you want to run the same tests on multiple apps concurrently, you have to start the dotnet test
command multiple times, once for each app/device that you want your tests to be executed on. Depending on your setup, you might want to replace the dotnet test
command with pytest
or any other command that you usually use to start your tests.
Note
In order to ensure that the dotnet test command is executed multiple times concurrently within the same terminal add an & at the end of the command to run it in the background.
Note
Make sure that your product names are different in case you started multiple instrumented apps on the same device, otherwise your tests might fail because they are using the same resources (ex. values saved to PlayerPref).
Ex1. Let’s say we want to run a set of tests on all apps started on Windows 11 (the exact platform version is displayed in the green popup and in AltTester® Desktop). For that, use the following code snippet:
altDriver = new AltDriver (host: "127.0.0.1", port: 13000, platformVersion: "Windows 11 (10.0.22621) 64bit");
altDriver = new AltDriver ("127.0.0.1", 13000, false, 60, "unknown", "unknown", "Windows 11 (10.0.22621) 64bit", "unknown", "unknown");
alt_driver = AltDriver(host="127.0.0.1", port=13000, platform_version="Windows 11 (10.0.22621) 64bit")
Initialize Altdriver host=127.0.0.1 port=13000 platform_version=Windows 11 ${SPACE}(10.0.22621) 64bit
Ex2. Let’s say we want to run the same set of tests on Windows and Android platforms. If you run your tests with pytest
, use the following code snippets:
In your test file:
def test(platform): alt_driver = AltDriver(host="127.0.0.1", port=13000, platform=platform)
In your conftest.py file:
def pytest_addoption(parser): parser.addoption("--platform", action="store", default="default name") def pytest_generate_tests(metafunc): option_value = metafunc.config.option.platform if 'platform' in metafunc.fixturenames and option_value is not None: metafunc.parametrize("platform", [option_value])
Then you can run from the command line with a command line argument:
pytest --platform "WindowsPlayer" & pytest --platform "Android"
Another way of doing this is with environment variables:
In your test file:
def test(): alt_driver = AltDriver(host="127.0.0.1", port=13000, platform=get_platform())
In your conftest.py file:
def get_platform(): return os.environ.get("PLATFORM", "")
Then you can set the environment variables and run from the command line the pytest
command:
export PLATFORM="WindowsPlayer" pytest & export PLATFORM="Android" pytest
Important
Although this version of AltTester® Unity SDK is backwards compatible, in case you have older versions of instrumented apps, you won’t be able to run your tests concurrently.
Using AltTester® Unity SDK in Release mode
By default AltTester® Unity SDK does not run in release mode. We recommended that you do not instrument your Unity application in release mode with AltTester® Unity SDK. That being said, if you do want to instrument your application in release mode, you need to uncheck RunOnlyInDebugMode
flag on the AltRunner script inside AltTester® Unity SDK asset folder AltTester/Runtime/Prefab/AltTesterPrefab.prefab
Logging
There are two types of logging that can be configured in AltTester® Unity SDK. The logs from AltDriver (from the tests) and the logs from the AltTester® Unity SDK (from the instrumented Unity application)
Note
From version 1.7.0 on logs from Server are referred to as logs from Tester.
AltTester® Unity SDK logging
Logging inside the instrumented Unity application is handled using a custom NLog LogFactory. The Server LogFactory can be accessed here: AltTester.AltTesterUnitySDK.Logging.ServerLogManager.Instance
There are two logger targets that you can configure on the server:
FileLogger
UnityLogger
Logging inside the instrumented app can be configured from the driver using the SetServerLogging command:
altDriver.SetServerLogging(AltLogger.File, AltLogLevel.Off);
altDriver.SetServerLogging(AltLogger.Unity, AltLogLevel.Info);
altDriver.setServerLogging(AltLogger.File, AltLogLevel.Off);
altDriver.setServerLogging(AltLogger.Unity, AltLogLevel.Info);
alt_driver.set_server_logging(AltLogger.File, AltLogLevel.Off)
alt_driver.set_server_logging(AltLogger.Unity, AltLogLevel.Info)
Set Server Logging File Off
Set Server Logging Unity Info
AltDriver logging
Logging on the driver is handled using NLog
in C#, loguru
in python and log4j
in Java. By default logging is disabled in the driver (tests). If you want to enable it you can set the enableLogging
in AltDriver
constructor.
Logging is handled using a custom NLog LogFactory. The Driver LogFactory can be accessed here: AltTester.AltTesterUnitySDK.Driver.Logging.DriverLogManager.Instance
There are three logger targets that you can configure on the driver:
FileLogger
UnityLogger //available only when runnning tests from Unity
ConsoleLogger //available only when runnning tests using the Nuget package
If you want to configure different level of logging for different targets you can use AltTester.AltTesterUnitySDK.Driver.Logging.DriverLogManager.SetMinLogLevel(AltLogger.File, AltLogLevel.Info)
/* start AltDriver with logging enabled */
var altDriver = new AltDriver (enableLogging: true);
/* start AltDriver with logging disabled */
var altDriver = new AltDriver (enableLogging: false);
/* disable AltDriver logging */
altDriver.SetLogging(enableLogging: false);
/* enable AltDriver logging */
altDriver.SetLogging(enableLogging: true);
/* set logging level to Info for File target */
AltTester.AltTesterUnitySDK.Driver.Logging.DriverLogManager.SetMinLogLevel(AltLogger.File, AltLogLevel.Info);
Logging is handled via log4j. You can use log4j configuration files to customize your logging.
Setting the enableLogging in AltDriver initializes logger named com.AltTester configured with two appenders, a file appender AltFileAppender and a console appender AltConsoleAppender
/* start AltDriver with logging enabled */
altDriver = new AltDriver("127.0.0.1", 13000, true);
/* start AltDriver with logging disabled */
altDriver = new AltDriver("127.0.0.1", 13000, false);
/* disable logging for com.AltTester® logger */
final LoggerContext ctx = (LoggerContext) LogManager.getContext(false);
final Configuration config = ctx.getConfiguration();
config.getLoggerConfig("com.AltTester").setLevel(Level.OFF);
ctx.updateLoggers();
Logging is handled via loguru.
Setting the enable_logging to True in AltDriver, all logs from alttester package are enabled.
/* start AltDriver with logging enabled */
alt_driver = AltDriver(enable_logging= True)
/* start AltDriver with logging disabled */
alt_driver = AltDriver(enable_logging= False)
/* enable logging in driver /*
loguru.logger.enable("alttester")
/* disable logging in driver /*
loguru.logger.disable("alttester")
Logging is handled via loguru.
Setting the enable_logging to True in AltDriver, all logs from alttester package are enabled.
/* start AltDriver with logging enabled */
Initialize AltDriver enable_logging=True
/* start AltDriver with logging disabled */
Initialize AltDriver enable_logging=False
/* enable logging in driver /*
Enable Loguru Logger alttester
/* disable logging in driver /*
Disable Loguru Logger alttester
Logging in WebGL
The logs for a WebGL instrumented build are displaied in the browser’s console. You can open the Console
tab by pressing F12
. To download the logs right click inside the Console
and choose Save as...
.
Code Stripping
AltTester® Unity SDK is using reflection in some of the commands to get information from the instrumented application. If you application is using IL2CPP scripting backend then it might strip code that you would use in your tests. If this is the case we recommend creating an link.xml
file. More information on how to manage code stripping and create an link.xml
file is found in Unity documentation
Generate testing reports using Allure
NUnit
Prerequisites
Allure installed on your system:
Windows: Scoop installation or Manual installation.
MacOS: use the following command in your terminal
brew install allure
.
NUnit project where all the test classes belong to a certain namespace.
(Not a must) VS Code installed with the Live Server extention.
*
surely you can use any other IDE if it has these features.
Setup
Add the Allure NUnit package to your project:
dotnet add package Allure.NUnit --version 2.9.5-preview.1
Other versions: https://www.nuget.org/packages/Allure.NUnit/
Create two folders called
allure-report
andallure-results
under your project.Add an
allureConfig.json
file at the following path/bin/Debug/netcoreappX
(where X is the version of your dotnet)Config file example.
the value of the
directory
property should be the full path to theallure-results
previously created folder.
In the tests files, import the AllureNUnit adapter
using NUnit.Allure.Core
.Use the attribute
[TestFixture]
and the[AllureNUnit]
under it.Additionally, you can add more attributes that increase the diversity of your report. See more examples here.
How to run the tests to obtain an Allure report
Execute tests to generate the output in the
allure-results
folder by using the command:dotnet test --results-directory allure-results
Generate a report in the
allure-report
folder:allure generate allure-results -o allure-report
How to check the results
Using VS Code and Live Server:
Navigate to the
allure-report
folder and open theindex.html
file with Live server.
Using an allure command:
allure serve allure-results
This command will generate a new report but not in a specific output. To find the report’s location, check the terminal output and there will be a message like Report successfully generated to PATH
where the path is the report’s location.
Examples
More details related to Allure can be found at the official Allure documentation.
Pytest
Prerequisites
Allure installed on your system:
Windows: Scoop installation or Manual installation.
MacOS: use the following command in your terminal
brew install allure
.
Pytest installed (
pip install pytest
)
Setup
Add the allure-pytest dependency to your project:
pip install allure-pytest
Create a folder called
allure-report
by using the following command in your terminal:allure generate
How to run the tests to obtain an Allure report
Execute tests to generate the output in the
allure-report
folder by using the command:pytest -v --alluredir=allure-report/ test_suite.py
For viewing the allure report use the following command after the previous:
allure serve allure-report/
How to obtain a single html report
In order to obtain a single html file with the whole report, you should use allure-combine
. Please follow the steps:
Install allure-combine using the following command in your terminal:
pip install allure-combine
Generate a non-combined report by using the follosing command:
allure generate -c allure-report -o allure-results-html
Generate a single html file with the whole report:
allure-combine ./allure-results-html
!
For MacOS, you should replace pip
with pip3
.
The name of the combined report is combined.html
and it is under allure-results-html
folder.
Examples
More details related to Allure can be found at the official Allure documentation.
Java
Prerequisites
Allure installed on your system:
Windows: Scoop installation or Manual installation.
MacOS: use the following command in your terminal
brew install allure
.
Maven installed on your system:
Windows: Guide from official Maven docs.
MacOS:
brew install maven
.
(Not a must) Allure-combine python package:
pip install allure-combine
.
Updating the pom.xml
Update the properties section of your
pom.xml
with the following info:<properties> <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding> <junit.version>4.13.2</junit.version> <allure.junit4.version>2.14.0</allure.junit4.version> <maven.compiler.plugin.version>3.5.1</maven.compiler.plugin.version> <maven.compiler.source>11</maven.compiler.source> <maven.compiler.target>11</maven.compiler.target> <aspectj.version>1.9.6</aspectj.version> <maven-surefire-plugin-version>3.0.0-M5</maven-surefire-plugin-version> </properties>
Update the build section of your
pom.xml
with the following info:<build> <plugins> <!-- Compiler plug-in --> <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-compiler-plugin</artifactId> <version>${maven.compiler.plugin.version}</version> <configuration> <source>${maven.compiler.source}</source> <!--For JAVA 8 use 1.8--> <target>${maven.compiler.target}</target> <!--For JAVA 8 use 1.8--> </configuration> </plugin> <!-- Added Surefire Plugin configuration to execute tests --> <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-surefire-plugin</artifactId> <version>${maven-surefire-plugin-version}</version> <configuration> <testFailureIgnore>false</testFailureIgnore> <argLine> -javaagent:"${settings.localRepository}/org/aspectj/aspectjweaver/${aspectj.version}/aspectjweaver-${aspectj.version}.jar" </argLine> <properties> <property> <name>listener</name> <value>io.qameta.allure.junit4.AllureJunit4</value> </property> </properties> </configuration> <dependencies> <dependency> <groupId>org.aspectj</groupId> <artifactId>aspectjweaver</artifactId> <version>${aspectj.version}</version> </dependency> </dependencies> </plugin> </plugins> </build>
Include in your dependecies section the following items:
<dependencies> <dependency> <groupId>com.alttester</groupId> <artifactId>alttester</artifactId> <version>2.1.2</version> </dependency> <dependency> <groupId>junit</groupId> <artifactId>junit</artifactId> <version>${junit.version}</version> <scope>test</scope> </dependency> <dependency> <groupId>io.qameta.allure</groupId> <artifactId>allure-junit4</artifactId> <version>${allure.junit4.version}</version> <scope>test</scope> </dependency> </dependencies>
For more information, check QA Automation expert tutorial.
How to run the tests to obtain an Allure report
Execute tests to generate the output in the
allure-results
folder by using the command:mvn test
For viewing the allure report use the following command after the previous:
allure serve allure-results
How to obtain a single html report
In order to obtain a single html file with the whole report, you should use allure-combine
which is a python package. Please follow the steps:
Install allure-combine using the following command in your terminal:
pip install allure-combine
Generate a non-combined report by using the follosing command:
allure generate -c allure-results -o allure-results-html
Generate a single html file with the whole report:
allure-combine ./allure-results-html
!
For MacOS, you should replace pip
with pip3
.
The name of the combined report is combined.html
and it is under allure-results-html
folder.
Examples
More details related to Allure can be found at the official Allure documentation.
